Introduction Quartz Tubes Sizes
Quartz tubes are essential components in a wide range of industrial, scientific, and semiconductor applications. Known for their high thermal resistance, corrosion resistance, and optical clarity, quartz tubes are critical for environments requiring purity and durability under extreme conditions. Whether you’re in semiconductor manufacturing or working with high-temperature furnaces, understanding the different quartz tube sizes is key to selecting the right product for your needs.
Understanding Quartz Tubes
What Are Quartz Tubes?
Quartz tubes are cylindrical structures made from high-purity silica glass. Their primary advantages include:
- Temperature resistance up to 1100–1200°C
- High chemical and thermal shock resistance
- Transparency in UV, visible, or IR spectra depending on material grade
- Non-reactivity with most chemicals and gases
Quartz Material Grades
- JGS1: Optical grade, transparent to UV and visible light
- JGS2: Transparent to UV light, commonly used in photonics
- JGS3: Infrared-transmitting, used in specialized IR applications
Standard Quartz Tube Sizes
Below is a reference chart of commonly available quartz tube sizes offered by Jiurui Quartz Products Co., Ltd.
Quartz Tube Size Chart (in mm)
| Outer Diameter (OD) | Wall Thickness | Inner Diameter (ID) | Common Lengths |
|---|---|---|---|
| 8 | 1.0 | 6.0 | 100mm, 300mm, 500mm |
| 12 | 1.5 | 9.0 | 200mm, 500mm, 1000mm |
| 20 | 2.0 | 16.0 | 100mm–1500mm |
| 25 | 2.5 | 20.0 | Custom lengths available |
| 50 | 3.0 | 44.0 | 100mm–2000mm |
| 100 | 5.0 | 90.0 | Cut-to-size available |
Factors to Consider in Quartz Tube Selection
- Temperature Resistance: Ensure the material matches thermal cycling needs.
- Inner Diameter: Crucial for fitting specific instruments or substances.
- Material Grade: Choose JGS1, JGS2, or JGS3 depending on optical transparency needs.
- Length Requirements: Jiurui offers custom cuts to meet precision engineering standards.
Customization Options for Quartz Tubes
Jiurui Quartz Products Co., Ltd. offers custom quartz components tailored to client specifications. Services include:
- Precision cutting and polishing
- Annealing for thermal shock resistance
- Custom flanges, joints, and bends
- Coating and etching for lab applications
Industries That Rely on Quartz Tubes
- Semiconductor: Wafer processing, chemical vapor deposition
- Laboratory: High-purity reactions, heating elements
- Lighting: UV lamps, halogen tubes
- Solar energy: Solar furnace experiments and reactors
- Optical Devices: Fiber optics, IR/UV transmission systems
Why Choose Jiurui Quartz Products Co., Ltd.
Jiurui Quartz has built a reputation for excellence through 15+ years of manufacturing experience, offering:
- Strict quality control in compliance with JGS1, JGS2, JGS3 standards
- Service to international research institutions and industrial firms
- Customization options for scientific, industrial, and semiconductor use
- Responsive engineering team to support rapid prototyping
Summary Table
| Aspect | Details |
|---|---|
| Common OD Sizes | 8mm to 100mm |
| Material Grades | JGS1 (UV+Visible), JGS2 (UV), JGS3 (IR) |
| Length Options | Standard 100mm–2000mm, custom sizes available |
| Applications | Labware, semiconductors, optical, solar, chemical |
| Manufacturer | Jiurui Quartz Products Co., Ltd. |
| Customization | Polishing, bending, flanging, annealing |
